您的当前位置:首页 > 产品信息 > CINCON电源模块 > CINCON砖式AC/DC模块电源 70W-700W系列
产品名称:CINCON砖式AC/DC模块电源 70W-700W系列
产品详细说明

Cincon AC-DC brick power supplies, also called AC-DC brick converter, could be used in fanless and harsh environment where also requires the power supplies to be encapsulated in order to avoid dusts. The output power range starts from 70W to 700W. In addition, Cincon offers three types of AC-DC brick power supplies. The first is the CBM series which is the all-in-one version covering the EMI solution inside the power supply. The second type is the PDF series which is for the system engineers who want to have the EMI solution on their own. For the PDF series, Cincon also offers detailed application notes including the EMI solution guideline. The third category is PFC series, the power factor correction (PFC) module. The PFC series is suitable to be applied with high input voltage DC-DC converters for distributed power architectures.



ITE/Industrial Brick Power

Model

Power

Input Voltage

Output Voltage

Features

Dimensions (Inch)

NEW

CBM70S

70W

90-264

12V, 24V, 36V, 48V

Low Profile
Wide Operating Temp.
Built-in EMI Filter & Capacitor
Class I

2.28x2.40x0.67

NRND

CBM100S

100W

90-264

12V, 24V, 28V, 36V, 48V

Build In Class B Filter

4.60x2.40x0.67

NEW

PDF700S

700W

90-264

12V, 24V, 28V, 48V, 56V

Low Profile
Built-in PFC
Altitude 5000
Class I

4.60x2.40x0.50

NEW

PFC750

750W

90-264

390V

Low Profile
Built-in PFC
Altitude 5000

2.28x2.40x0.50
